1000 мл/мин Расход 3/6 роликов шаговый двигатель 24 В перистальтический насос штабелируемые головки насоса

Model No.

Description

SKU

Compatible Tubing

BJ30-YZ1515X-3B-DD

YZ1515X 3 roller white big motor

YZ15 3R White BM

ID1.6*WT1.6 (#14)

ID3.2*WT1.6 (#16)

ID4.8*WT1.6 (#25)

ID6.4*WT1.6 (#17)

ID8.0*WT1.6 (#18)

BJ30-YZ1515X-3B-DX

YZ1515X 3 roller white small motor

YZ15 3R White SM

BJ30-YZ1515X-3H-DD

YZ1515X 3 roller black big motor

YZ15 3R Black BM

BJ30-YZ1515X-3H-DX

YZ1515X 3 roller black small motor

YZ15 3R Black SM

BJ30-YZ1515X-6B-DD

YZ1515X 6 roller white big motor

YZ15 6R White BM

BJ30-YZ1515X-6B-DX

YZ1515X 6 roller white small motor

YZ15 6R White SM

BJ30-YZ1515X-6H-DD

YZ1515X 6 roller black big motor

YZ15 6R Black BM

BJ30-YZ1515X-6H-DX

YZ1515X 6 roller black small motor

YZ15 6R Black SM

BJ30-YZ2515X-3B-DD

YZ2515X 3 roller white big motor

YZ25 3R White BM

ID4.8*WT2.5 (#15)

ID6.4*WT2.5 (#24)

BJ30-YZ2515X-6B-DD

YZ2515X 6 roller white big motor

YZ25 6R White BM

Model No.

BJ30-YZ1515X-3B/3H/6B/6H-DD/DX

BJ30-YZ2515X-3B/3H/6B/6H-DD/DX

Pump Roller

SST 3/6 rollers

Pump Head

ABS engineering plastic

Fast Tubing

YES

Pump Color

White/Black

Motor Type

57 Stepper motor (=NEMA 23 motor)

Motor Speed

0-400rpm

Flow Range

0-1700ml/min

Tubing Size

ID1.6-8.0mm  WT1.6-2.5mm  OD≤11.4mm

Tubing Life

Silicone≥200H  BPT Rubber≥1000H

Pressure Rating

Up to 2 bar(30psi)

Working Environment

0-40℃, <80% non-condensing

Max DB

65db

Suction

5m

Head

8m

Dimension (L*W*H)

175.2*122.1*106mm

Net Weight

1525g(3 roller)/1585g(6 roller)


Material

Features

Service Life

Silicone

Food grade, High flexibility Temp. range -4℃ - +180℃    For non-corrosive liquid

≥200h

Pharmed BPT

Saint-Gobain, standard Temp. range -51℃- +132℃   Anti weak acid and alkali

≥1000h

Viton

MasterFlex,  Standard Temp. range -20℃- +260℃   Anti strong acid and alkali

≥1000h
