This section locks with a single lamp , factory spot , ex-factory price feedback ! Limited number !

Specifications:

[Brand] : Dual Force

[Category] : double tongue mortise lock tumbler

[Model] : TH-32 single lamp

[Origin] : Wenzhou ( Yongjia )

[Texture] : total iron material

[ Panel ] : 185 × 50MM

[ Lock ]: small carabiner body 50

[ Cylinder ]: small aluminum cylinder 68

[ Pitch ] : 50MM

[Package] : 20 / box

[Applicable ]: room door , interior door , wooden door locks, home lock

Colour : SN / NP, SN / CP, BN / GP, SN / KG, BN / KG

Surface treatment description:

AB ----- AC ----- Red bronze Bronze

AE ----- ivory gold brown BB -----

BN/GP----- gun black gold K gold titanium black BN/KG-----

CP ------ bright chrome imitation gold GP -----

GP/SN----- brushed KG ----- K gold

MAB ----- Asian bronze MAC ----- Asian red bronze

MAE ----- bright nickel matte coffee NP -----

RGP ----- 22K gold brushed gold SG -----

SN ------ brushed chrome brushed SN/CP-----

SN / KG ----- K gold / brushed goldSN/NP----- Brushed Nickel

Accessories overview :

Packing diagram:

Packing diagram template for reference only, actual product and product specific requirementsConfiguration prevail

[Note] : fixed cylinder key hole kept clean, dry , smooth case unlocking enough not to inject any other inner cylinder lubricant oils ,

Otherwise it will shorten the life of the lock , as long as you tooth and key in the key hole by adding a little special lubrication powder lubrication ( toner ) , so on the line.

Door installation steps :

A. Make sure the incline of the tongue with the closing direction , when you need to adjust the direction of the door lock , poke upward slanting tongue commutator segments , the oblique tongue promote the lock, rotate 180 , according to the intallation draw lines and make holes .

B. will lock into the hole .

C. pretension liner screws.

D. The square bar through the door into the lock.

E. Install the inner and outer plates , making handle smoothly, fix the screws, so the key and knob smoothly.

F. install the gusset plate and gusset box , alignment lock, bolt and match should be made smooth and tighten the screws.

Warranty:

1 , special attention is , in the absence of paint brush before opening paint dry before the lock installed. Do not install the wet paint on the door . Paint volatile gases reduce the useful life .

2 , locks the door switch during weekdays , it is best to perform hand holding bolt screwed into the lock, closed the door and then let go , do not force Zhuangmen , otherwise it will reduce the service life. Locks used for a period of time , it will not be opened smoothly phenomenon, do not drip oil into the lock cylinder , the talcum powder or pencil fines within the heart of the heart can slide lock .

3 In addition, do not use a damp cloth to wipe the lock and handle, because some metallic lock might get rusted ; locks alloy plating will wear off , losing aesthetic effect .

4 ,Should be prevented from corrosion , contamination can not make locks .

I plant the full range of locks , cheap, good service, timely delivery, "customer first " philosophy .
