13inch 260 E-Motorcycle Hub Motor(35H) 2000W V1 Type | Автомобили и мотоциклы

13inch 260 E-Scooter Hub Motor(35H) 2000W V1 Type

13inch 260 Hub Motor specially designed for electric motorcycle or electric scooters, the rated power can be made at 1500W,2000W,3000W or 5000W. Max speed can be customs at 35-100km/h.

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnet
2. Motor design: Double axle out with 13inch rim
3. Rim size:3.5x13
4. Matching Tire: 130/70-13
5. Magnet Height: 35MM
6. No. of Pole Pairs: 23 pairs
7. Rated Power: 2000W
8. Max Power: 2500W
9. Rated Voltage: 48V( 60V/72V Can be optional)
10. Speed: 45km/h (30-60km/h can be customized)
11. Max No-load RPM: 650RPM
12. Max Torque: 110N.M
13. Max Efficiency: 86%
14. Continious current:48A
15. Max current:60A
16. Brake type: Disc brake
17. Rear Fork width for installation: 200mm
18. Winding Core Material: Iron
19. Cross Section of Phase wire: 6 mm2
20. Hall sensor phasing angle: 120 degree
21. Temperature Sensor: Optional
22. Max. Working Temperature: 70 degree, Peak 120 degree
23. Waterproof Grade: IP54
24. Color: Black
