Product Description



Type	6040
Max working travel	XYZ=400*570*75mm
Machinable material thickness	≤100mm
Dimensions	750*570*390mm
Frame material	6061-T5 aluminium alloy
Track type	Chrome-plated + linear bearing
Spiral type	Ball screw, diameter of 16mm, Thread pitch 5mm
Mechanical resolution	XYZ axis:0.0025mm/step
PositionaI accuracy	0.05mm
Spindle motor	Frequency conversion spindle, 0.8kw
Revolving speed	24000rpm/min
Holder	ER11(3.175mm,6mm)
XYZ motor	Stepper motor JK57HS76-4204B-01AF
Stepper driver	High performance, independent of each axis
Feed rate	2000mm/min
Communication Interface	USB2.0
System requirement	WIN-XP or WIN-7
Instruction code	G code/.nc/.ncc/ .tab/.txt
Voltage	Input 85V-240VAC(400HZ)
Operating environment	Temperature: 5℃-40℃; Humidity: 35%-80%
Packaging size	45.8kg (86*62*48mm)



Warm Tips: This price is the promotion price of our company in the middle of the year. If you are interested in buying, please do not hesitate, because it is really suitable.



Application

Wide range of application:

Such as seal, packing, scutcheon and pane making, decorating, art and craft, architecture model, souvenir,

badge, electric circuitry and carpentry field.

Suitable for Materials:

Engrave and cut on Acrylic sheet, ABS double color sheet, PVC foam sheet, wooden sheet, PCB Aluminum,

brass, steel.



Features

​a. Working platform is cast wholly and firmly with aluminum alloy.

b. Desktop table model, small size easy to move and use, smart working,  high precision.

c. High speed stepper driver and motor system, high working efficiency.

d. Dust-proof and water-proof device ensures the machine safe, clean and easy for maintenance.

e. Human-friendly design, easy operating and transporting.

f. advanced Mach3 control system with memory to ensure the processing point when the blade is broken or power off situation.

g.Specific saving mode of different points.

h.1.5KW spindle head does not only increase the fineness of engraving the breast card without screw and the under base is more flat and smooth. The machine is suitable for the architecture mould sign industry, school, enterprise, government to use.



Our Services

1.Warm Tips:

All the parts of machine can do some changes to meet your requirements.

1.motor (step motor or servo motor optional)

2.spindle (air cooled or water-cooled optional )

3.guide rail (linear guide rail or square linear guide optional )

4.the table of the machine (Vacuum table,T-shot table,Combination of T-shot &Vacuum table,Normal table,Table moving)

2.Payment terms:

1 You can pay 30% by T/T(bank transfer)   in  advance ,when we finished the machine ready for shipping ,you pay the  70% left.

2 You can pay by  Escrow  by  Alibaba

3.Delivery time:

within10working  days.If we see the scanner of  bank  receipt /confirmation by email ,we  will take into producing ,ad ship it to you .

4.Our technical support and quality assurance as follows:

1.warranty:1 years

2.replace all accessories during the waranty period for free(except wearing parts and artificial damage)

3.Provide 24 th technology online support



Company Information



FAQ



1. I never use this kind of machine before, is it easy to learn?

User-friendly English manual and operation video will be sent together with the machine, if there is still any question, we can talk through phone or Skype.

Moreover, you could come to our factory to learn how to use it before shipment. Our technician will give you professional guidance.

2. If the machine has problem, what can you do to help?

Free parts will send to you within warranty time, and there are 24/7 technique support by mail and phone. our after-sales staff can come to your workshop if the problem still cannot be fixed.

3. How could I know if this machine is suitable for me?

Before ordering, we will provided every details of the machine for your reference, or you could tell us your work piece, our techniciant will recommend the most suitable machine for you. Furthermore, we can make a sample in advance for you to check if your drawing is provided.

---

---
