TOPBSNA Android 10 Car DVD Player GPS For CHEVROLET AVEO/Sonic 2011-2013 WIFI Multimedia Stereo 1 Din Radio Headunit RDS | Автомобили и

---

Need Your Attention Please​​​​



• To make sure that the car radio is really compatible with your car, please compare the shape & size of the car radio and the power cable connector with your original car firstly.
• If you do not know how to compare, please contact our customer service to check.(To save your time, please send your car name,year and console photo firstly .

The Newest free map including the following area and country:



• North America: Canada,Mexico,United States
• Asia: Indonesia,India.Malaysia,Philippines,Singapore,Thailand,Vietnam
• Europe:Albania,Andorra,Austria,Belgium,Bosnia,Bulgaria,Croatia,Cyprus,CzechRepublic,Denmark,Estonia,Finland, France,Germany,Gibraltar,Greece,Hungary,Iceland,Ireland,Italy,Kosovo,Latvia,Liechtenstein,Lithuania,Luxembourg,Malta,Moldova,Monaco,Netherlands,Norway,Poland,Portugal,Romania,San_Marino,Serbia,Slovakia,Slovenia,Spain,Sweden,Switzerland,Turkey,United Kingdom
• South America: Argentina,Brazil,Chile,Colombia.Peru,Uruguay,Venezuela
• Oceanica : Australia, New Zealand.
• Africa : Angola,Botswana,Burundi,Egypt,Lesotho,Kenya,Malawi,Morocco,Namibia,Nigeria,Rwanda,South- Africa,Swaziland,Tanzania,Uganda,Zambia,Zimbabwe
• Mid-East: Bahrain,Israel,Lebanon,Oman, Qatar, Kuwait,Saudi Arabia,The United Arab Emirates, Jord.

1. We will install the map according to your shipping address if there are no any requirment.
2. If you need the map for other country，pls you with us contact or leave a message .​



KEY Point:



• OS:system Android 10
• ​Main Frenqency:1.5GHz
• ​CPU:Octa-Core 64 bit PX5 Cortex-A53 1.5GHZ Frequency
• RAM:SAMSUNG 4GB DDR3
• ​Nand Flash:64 GB
• ​Amplifer IC:ST TDA7851
• ​1024*600 HD Capacitive multi-touch screen
• ​​Radio IC:NXP TEF6686

​

Spain Warehouse:



• No VAT, No import tax,  {only from spain Shippment} 2-5 days deliver.
• Ship to EU countries: Spain, Portugal, France, Germany, Italy, Slovenia, Denmark, Poland, Austria,
• Netherlands, Hungary, Czech Republic,Belgium, Luxembourg, United Kingdom, Slovakia,Croatia,Romania,
• Bulgaria,Estonia,Ireland,Latvia,Lithuania,Finland,Sweden.
• Notice ：we can't delivery to those area,if you address is other area,please don't order.
• Zip code : 35000-35999,38000-38999,23030,22060 or CH-6911,99010-99810,9000-9999.
• when you place an order before ，pls you with me confirm Whether have spain stock ,if no have we will default from china help you shippment .



Installation tips:



•  In order to insert DVD/CD, Please remove the screws on top of the car DVD before you install it in the car.
•  Please don't install the car radio with power on. You should turn on your car key after you install the car radio.
•  When you turn on the car key, the car radio will automatically start, so there's no need to press the power button.



support these ：



•  Support WIFI：Buit in WiFI dongle with WiFi antenna
•  Support：DVR {Optional}
•  Support : {DAB AntennaOptional}
•  Support :TMPS {Optinal}
•  Support : OBD Optional Support OBDII -oh Board  Diagnostics
•  Support : Digital TV {Optinal}
•  Support :Steering Wheel plug and play



TOPBSNA Android 10 Car DVD Player GPS For CHEVROLET AVEO/Sonic 2011-2013 WIFI Multimedia GPS Stereo 1 Din Car Radio Headunit RDS

           System and Hardware Parameters (Octa-Core)

OS	Android 10  System
CPU	Octa-Core 8*1.5Ghz
RAM	SAMSUNG DDR3 4GB
Flash	64 GB
Display Size	8 inch Display 1024*600
Screen	Capacitive and Multi-touch Screen (Original Hanstar Screen )
Panel Buttons Colour	Red
Radio	FM1,FM2,FM3,AM1,AM2
GPS	Ublox 6; Support GPS
TFT Drive IC	PX5
Loader	FORYOUDL-30
Pick Up	HITACHI 1200XH
Motor Drive	MABUCHI
Amplifer IC	ST TDA7851
DVD Decoder IC	Sunplus 8202TQ
Radio IC	NXP TEF6686
Power Supply	4*50W (MOSFET OUTPUT)
Bluetooth	CSR
Video Decoder	HD 1920*1080
WiFi	Built-in
Video Input	Front camrea,Rear camera,AUX
Audio Input	AUX-L;AUX-R (2 way)
Video Output	Vieo1,Video2 (2 way)
Audio Output	FL;FR;RL;RR and Subwoofer (5 Way)
USB Port	USB1;USB2;
USB Device Support	2TB Hard Disc
SD Card Port	Madia Card and Map Card (2 Way)
Multi Media Parameters
Music Format	MP3、WMA、AAC、RM、FALC etc
Video Format	MPEG-1/2/4、H264、H263、VC1、RV、RMVB、DivX、Sorenson SparK、Spark、VP8、AVS Stream…
Picture Format	JPG/BMP/JEPG/GIF/PNG
Radio Parameters
Frenqency Range	FM：76.0MHz-108.0MHz
Frenqency Range	AM: 522KHz-1620KHz
Country	China,Europe,Eastern,Europe,Russia,USA1,USA2,Japan etc.
DVD Parameters
Video output range	1.0V-1.2V(75Ω)
Compatible Disc	DVD/DIVX/MP4/MP3/MP2/VCD
Amplifer Parameters
Test Voltage	13.8V
Max Output Power	4*80W
GPS Parameters
Operation System	Android 10 system
Support Map	Android  Map
Main Frenqency	1.6GHz
Map Solution	Navitel,iGo etc.
WIFI Parameters
Power supply	Vcc_3.3V
Suppoted Protocol/Standard	IEEE802.11B/g/n compatible WLAN
Interface Type	USB2.0
Frequency	2.4-2.484GHz
Modulation	OFDM/DBPSK/DQPSK/CCK
RF Power	15dBM









---

---
